Frame
Lumen eRIDE Carbon HMX Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Fork
FOX 34 Float Rhythm Air Grip 3-Modes / Kabolt 15x110mm axle / tapered steerer 44mm offset / Reb. Adj. / Lockout / 130mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Custom large Air volume / DPS / Reb. Adj. Travel 130-90-Lockout / T165X45mm
Remote System
SCOTT TwinLoc Suspension System 3 modes front and rear / integ. Grip clamp
eDrive System
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 32kph, TQ Internal 360Wh, TQ HPR Bluetooth / ANT+ / Dedicated Smartphone app
Rear Deraileur
Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shifter(s)
Shimano Deore SL-M6100-IR / Rapidfire Plus Ispec EV clamp
Crankset
FSA Alloy crankset / 175mm / 34T
Cassette
Shimano CS-M6100 / 10-51 T
Brakes
Shimano Deore M6120 4 Piston Disc
Handlebar
Syncros Fraser 2.0 DC Alloy 6061 D.B. mini Rise / back sweep 8° / 760mm Syncros Performance XC lock-on grips
Stem
Syncros DC 2.0 Syncros Cable Integration System 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.0 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Saddle
Syncros Tofino 1.5 Regular, Titanium rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Hub Front
Formula CL-811 / 15x110mm
Hub Rear
Formula CL-148M / 12x148mm / Micro Spline Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
Rims
Syncros X-30SE / 32H / 30mm Tubeless ready
Tires
FRONT TIRE: Schwalbe Wicked Will 29x2.4" EVO Super Race / TLE / 67EPI / Addix Speed Soft REAR TIRE: Schwalbe Wicked Will 29x2.4" EVO Super Race / TLE / 67EPI / Addix Speed Grip
