Frame
AluminumSpark Alloy SL 6011 Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
RockShox Pike RL3 Air Custom Charger 3-Mode Damper 15x110mm Maxle Lite / 44mm offset / Tapered steerer Lockout / Reb. Adj. / 130mm travel
Rear Shock
RockShox Deluxe Select RL3 Trunnion 3 modes / Lockout-Trail-Descend Debon Air / Reb. Adj. Travel 120mm / T165X45mm
Remote System
SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes
Rear Deraileur
SRAM GX Eagle 12 Speed
Shifter(s)
SRAM NX Eagle Trigger
Crankset
SRAM X1 Eagle DUB 55mm CL / 32T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Cassette
SRAM SX-PG1210 / 11-50 T
Brakes
Shimano MT501 Disc
Handlebar
Syncros Fraser 2.0 DC Alloy 6061 D.B. mini Rise / back sweep 8° / 760mm Syncros Performance XC lock-on grips
Stem
Syncros DC 3.0 Syncros Cable Integration System 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.0 31.6mm / S size 100mm/ M size 125mm / L size 150mm / XL size 170mm
Saddle
Syncros Tofino 2.5 Regular
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Hub Front
Formula CL-811 / 15x110mm
Hub Rear
Formula CL-148S / 12x148mm Syncros Axle w/Removable Lever with 6mm Allen T30 and T25 Tools
Rims
Syncros X-30SE / 32H / 30mm
Tires
Schwalbe Wicked Will 29x2.4" Performance / TLR / Foldable / Addix
Weight (Approx lbs)
31.97 (with tubes)
