Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Bottom Bracket | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel. FORM™ Alloy Rear Triangle
Fork
RockShox Zeb Select RC 170mm | 27.5 = 38mm Offset | 29 = 44mm Offset
Rear Shock
Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
Rear Deraileur
Shimano Deore 12spd
Shifter(s)
Shimano Deore 12spd
Crankset
Race Face Ride Cinch | 32T | 24mm Spindle | Crankarm Length: SM = 165mm | MD - XL = 170mm
Bottom Bracket
Shimano Threaded BBMT501-B
Cassette
Shimano Deore 10-51T 12spd
Brakes
Shimano MT6120 4 Piston | Metal Pads
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Seatpost
X Fusion Manic Composite 30.9mm | SM = 150mm | MD = 170mm | LG - XL = 200mm
Headset
FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Shimano TC500 | 15x110m
Hub Rear
Shimano TC500 Boost 148mm
Rims
WTB ST i30 TCS 2.0 Tubeless | 32H / Tubeless Ready - Tape / Valves Incl
Tires
F: Maxxis Minion Assegai 2.5 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready
Weight (Approx lbs)
38.016
