Frame
FORM™ Alloy | Integrated Display | LC2R Suspension System | Threaded BB | RIDE-4™ Adjustable Geometry + Suspension Rate | 160mm Travel | FORM™ Alloy Rear Triangle
Fork
Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Rear Shock
Fox Float X2 Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | SM = 210 x 55mm | MD - LG - XL = 230 x 65mm | Size-Specific tune in FAQ
eDrive System
Drive System:Dyname S4 Pro Mountain Bike Drive | 250w Nominal Power | 750w Max Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada Battery:720 Wh Removable Integrated Li-Ion | 100% Charged in 3
Rear Deraileur
Sram Eagle Transmission
Shifter(s)
Sram Eagle Transmission
Crankset
Race Face Aeffect Cinch | 34T T-Type Ring | 24mm Spindle | SM - XL = 165mm
Chain
Sram Eagle Transmission
Cassette
Sram Eagle Transmission 10-52D
Brakes
Sram Maven Bronze Stealth 4 Piston | Metal Pads
Handlebar
Rocky Mountain AM | 780mmWidth | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Stem
Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Seatpost
X Fusion Manic Composite 30.9mm | SM = 125mm | MD = 150mm | LG = 170mm | XL = 200mm
Saddle
WTB Solano Fusion Form 142 | Cromoly Rails
Headset
FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Rocky Mountain SL Sealed Boost 15mm
Hub Rear
Novatec E-MTB SL Pro Boost 148mm
Rims
Race Face ARC 30 | 32H | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
Tires
Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
