Frame
FORM™ Alloy | Press Fit BB |Integrated Display | Internal Cable Routing | 197mm Rear Spacing | Tapered Zerostack Headtube | Dropper Post Compatible. Rear Triangle
Fork
Rocky Mountain Carbon Fat
eDrive System
Drive System Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada Battery 720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55
Rear Deraileur
MicroShift Advent X 10spd With Clutch
Shifter(s)
MicroShift Advent X 10spd E
Crankset
Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM-MD = 170mm | LG-XL = 175MM
Cassette
MicroShift CS-EH104 11-48T
Brakes
Sram Level 2 Piston | Resin Pads
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Stem
Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Seatpost
Rocky Mountain 30.9mm
Headset
FSA Orbit NO.57E ZS44|56 | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Rocky Mountain Sealed 150 x 15mm
Hub Rear
DT Swiss 350 197mm | 36T Star-Ratchet
Rims
WTB KOM Light i76 | TCS Tubeless | 32 H | Tubeless Ready - Tape / Valves Incl
Tires
F: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Incl. Not Installed) // R: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Incl. Not Installed) //
Weight (Approx lbs)
54.5 LBS|24.7 KGS
