| Frame | FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle |
| Fork | RockShox Recon Silver RL 150mm | 42mm Offset |
| Rear Shock | RockShox Deluxe Select | Sealed Bearing Eyelet | 25x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ |
| Remote System | |
| Rear Deraileur | Shimano Deore 11spd |
| Front Deraileur | |
| Shifter(s) | Shimano Deore 11spd |
| Crankset | Rocky Mountain Microdrive | 32T |Sram 76mm BCD | 24mm Spindle | Crank Length: XS = 165mm | SM - XL = 170mm |
| Bottom Bracket | Rocky Mountain Sealed BB92 - Shimano Compatible |
| Chain | KMC X11-1 |
| Cassette | SunRace CSMS8 EA1 11-51T |
| Brakes | Tektro HD-M275 | Shimano Pad Compatible | F:Tektro 180mm | R:Tektro 180mm |
| Handlebar | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40m |
| Seatpost | Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm |
| Saddle | WTB Volt 142 |
| Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Hub Front | Rocky Mountain Sealed Boost 15mm |
| Hub Rear | Novatec D462 Sealed Boost 148mm |
| Rims | Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape / Valves / Sealant Not Incl |
| Tires | WTB Trail Boss Comp 29 x 2.4 |
| Weight (Approx lbs) | 35.6 LBS|16.1 KGS |
