Frame
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle
Fork
RockShox 35 Gold RL 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset
Rear Shock
RockShox Deluxe Select RT | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ
Rear Deraileur
Shimano Deore 12spd
Shifter(s)
Shimano Deore 12spd
Crankset
Shimano Deore | 32T | 24mm Spindle | Crankarm Length: XS - SM = 165mm | MD - XL = 170mm
Bottom Bracket
Shimano SM-BBMT500
Cassette
Shimano Deore 10-51T 12spd
Brakes
Shimano MT4120 4 Piston | Resin Pads
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm
Seatpost
X Fusion Manic Composite 30.9mm | XS = 125mm | SM = 150mm | MD - LG = 170mm | XL = 200mm
Headset
FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Shimano TC500 | 15x110m | 28H
Hub Rear
Shimano TC500 Boost 148mm | 28H
Rims
WTB ST i30 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl
Tires
Maxxis Dissector 2.4 WT EXO Tubeless Ready
Weight (Approx lbs)
36 LBS|16.3 KGS
