Frame
SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle
Fork
RockShox Lyrik Select+ 150mm | Charger RC3 Damper | 27.5 = 37mm Offset | 29 = 42mm Offset
Rear Shock
RockShox Super Deluxe Ultimate | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ
Rear Deraileur
Sram X0 Transmission Wireless
Shifter(s)
Sram AXS Wireless Pod Controller
Crankset
Sram X0 Transmission Alloy | 32T | DUB Spindle | Crankarm Length: XS -SM = 165mm | MD - XL = 170mm
Bottom Bracket
Sram BB92 DUB Wide
Chain
Sram GX Transmission
Cassette
Sram GX Transmission 10-52T
Brakes
Sram G2 RSC 4 Piston | Resin Pads
Handlebar
Rocky Mountain AM Carbon 780mm
Stem
Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Seatpost
OneUp Dropper 30.9mm | XS = 120mm | SM = 150mm | MD = 180mm | LG - XL = 210mm
Headset
FSA Orbit NO.85 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Rocky Mountain SL Sealed Boost 15mm
Hub Rear
DT Swiss 370 Boost 148mm | 18T Star-Ratchet
Rims
Rocky Mountain 30AM Carbon / Tubeless Ready - Tape / Valves Incl
Tires
F: Maxxis Dissector 2.4 WT 3C MaxxTerra EXO Tubeless Ready // R: Maxxis Dissector 2.4 WT 3C MaxxTerra EXO Tubeless Ready //
Weight (Approx lbs)
30 LBS|13.6 KGS
