Frame
SMOOTHWALL™ Carbon | Penalty Box 2.0 Storage | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 29" = 150mm | 27.5" = 140mm | SMOOTHWALL™ Carbon Rear Triangle
Fork
RockShox Lyrik Ultimate Flight Attendant 160mm | Auto-Adjust Flight Attendant Damper | 27.5 = 37mm Offset | 29 = 42mm Offset
Rear Shock
RockShox Super Deluxe Ultimate Flight Attendant | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x55mm | Size-Specific tune in FAQ
Rear Deraileur
Sram XX Eagle Transmission Wireless
Shifter(s)
Sram AXS Pod Ultimate Controller
Crankset
Sram XX Transmission Carbon | 32T | Power Meter | DUB Spindle | Crankarm Length: XS -SM = 165mm | MD - XL = 170mm
Bottom Bracket
Sram BB92 DUB Wide
Chain
Sram XX Transmission
Cassette
Sram XX Eagle Transmission 10-52T
Brakes
Sram Code Ultimate Stealth 4 Piston | Metal Pads
Handlebar
Race Face ERA | XS = 760mm | SM - XL = 780mm Width | 20mm Rise | 8° Backsweep | 5° Upsweep | 35mm Clamp
Stem
Race Face Turbine R | 0° Rise | All Sizes = 40mm
Seatpost
Rock Shox Reverb AXS Wireless Post | XS = 125mm | SM = 150mm | MD - XL = 170mm
Saddle
WTB Volt Fusion Form 142 | Titanium Rails
Headset
FSA Orbit NO.85 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Tires
Maxxis Minion DHF 2.5 WT 3C MaxxTerra EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | Tubeless Set Up | Sealant Incl
