Frame
FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry | 150mm Travel | FORM™ Alloy Rear Triangle
Fork
RockShox Lyrik Select+ 160mm | Charger 3.1 RC2 Damper | 27.5 = 37mm Offset | 29 = 42mm Offset
Rear Shock
SM-XL: Rock Shox Super Deluxe Select+ | 230x60mm | XS: Rock Shox Deluxe Ultimate | 210x55mm | Sealed Bearing Eyelet | 25x8mm F Hardware | Size-Specific tune in FAQ
eDrive System
Drive System Dyname S4 Lite Mountain Bike Drive | 250w Nominal Power | 550w Max Power | 65Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada Battery 480 Wh Removable Integrated Li-Ion Display Rocky Mounta
Rear Deraileur
Sram GX Eagle Transmission Wireless
Shifter(s)
Sram AXS Pod Controller
Crankset
Race Face Turbine Cinch | 34T T-Type Ring | 30mm Spindle | XS - XL = 165mm
Chain
Sram GX Eagle Transmission
Cassette
Sram GX Eagle Transmission 10-52T
Brakes
Sram Code Bronze Stealth 4 Piston | Metal Pads
Handlebar
Rocky Mountain AM | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Stem
Rocky Mountain 35 AM | 0° Rise | All Sizes = 40mm
Seatpost
OneUp V3 Dropper 30.9mm | XS - SM = 120mm | MD = 150mm | LG = 180mm | XL = 210mm
Saddle
WTB Solano Fusion Form 142 | Cromoly Rails
Headset
FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Hub Front
Novatec D791SB Sealed Boost 15mm
Hub Rear
DT Swiss 370 Boost 148mm | 18T Star-Ratchet
Rims
Race Face ARC 30 | 32H | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
Tires
Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready | Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO+ Tubeless Ready | Cushcore Trail Tire Inserts | Lightweight | Tire & Rim Protection
Weight (Approx lbs)
48.4 LBS|22 KGS
