Frame
Ransom Carbon HMF Mainframe with Alloy 6061 Swingarm Integrated Suspension Technology 6 Link kinematic / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline / MX Ready
Fork
FOX 38 Float Performance Elite Grip 2 Air HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle 44mm offset / tapered steerer 170mm travel
Rear Shock
FOX FLOAT X NUDE EVOL Piggy Back Trunnion / SCOTT custom w. travel / geo adj. 3 modes: Climb-Ramp Control-Descend Custom large Air volume / Comp & Reb. Adj. Travel 170-130-Climb / T205X65mm / Bearing Hardware
Remote System
TracLoc Technology Rear Suspension & Dropper Remote 3 Rear Suspension modes
Rear Deraileur
SRAM GX Eagle AXS Transmission 12 Speed Wireless Electronic Shift System
Shifter(s)
SRAM AXS Rocker Controller
Crankset
SRAM GX Eagle Transmission Bash guard / DUB / 55mm CL / 32T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN GX Eagle Transmission
Cassette
SRAM GX Eagle XS 1275 Transmission 10-52
Brakes
SRAM Code RSC Stealth 4 Piston Disc
Handlebar
Syncros Hixon iC Carbon Size S & M 15mm rise / Size L & XL 25mm rise back sweep 8° / 780mm / 40mm Syncros Endurance lock-on grips
Seatpost
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm S size 140mm / M size 180mm / L & XL size 210mm
Saddle
Syncros Tofino 1.5 Titanium Rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Rims
Syncros Revelstoke 2.0 6 Bolt F: 15x110mm R: 12x148mm Boost 30mm Tubeless ready rim 28H / XD Driver Syncros Axle w/Removable Lever with Tool
Tires
FRONT TIRE: Maxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp REAR TIRE: Maxxis Dissector / 2.4" / 120TPI Foldable / DD/ TR / 3C Maxx Terra
Weight (Approx lbs)
34.61 (Tubeless setup without Matchbox IS)
