Frame
Alloy Frame / Virtual 4 link kinematic VLK 27.5" and 29" compatible / geo adj. / Boost 148x12mm 180mm travel / Bosch Gen4 / Integr. removable Battery Tapered Headtube E2, Central Kickstand Mount
Fork
FOX 38 Performance Elite / Air / eMTB+ FIT Grip 2 / LSC-HSC / LSR-HSR / 15x110mm QR axle tapered steerer / Reb. Adj. / 180mm travel
Rear Shock
FOX Float X2 Performance / Air LSC, LSR w/2-Pos. lever
eDrive System
Bosch Performance CX EU: 25kmh / INT: 20mph, PowerTube 625Wh, Bosch Purion
Rear Deraileur
SRAM X01 Eagle / 12 Speed
Shifter(s)
SRAM NX Eagle Single Click
Crankset
SRAM X1 1000 / 165mm / 34T
Cassette
SRAM XG1275 / 10-52 T
Brakes
Shimano XT / BR-M8120 4 Piston
Handlebar
Syncros Hixon 1.5 Rise / Alloy 2014D.B. 20mm rise / 8° / 800mm Syncros Pro lock-on grips
Stem
Syncros XM1.5 / Alloy 6061 integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
Seatpost
FOX Transfer Dropper Post 31.6mm / S size 125mm / M size 150mm / size 175mm / XL size 200mm
Saddle
Syncros Tofino 1.5 Regular Titanium rails
Headset
Acros Blocklock / Tapered 1.5"-1 1/8" OD 52/62mm / ID 44/56mm
Hub Front
Formula CL-811 / 15x110mm
Hub Rear
Formula ECT-1481 / Boost 148x12mm
Rims
Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
Tires
FRONT TIRE:Maxxis Assegai 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra REAR TIRE:Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra
Weight (Approx lbs)
54.23 (with tubes)
