Frame
Alloy Frame / Virtual 4 link kinematic VLK, 27.5″ and 29″ compatible / geo adj. / Boost 148x12mm, 180mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount
Fork
RockShox ZEB / Air 15x110mm QR axle tapered steerer / Reb. Adj. / 180mm travel
Rear Shock
FOX Float X2 Performance / Air LSC, LSR w/2-Pos. lever
eDrive System
DRIVE UNIT – Bosch Performance CX EU: 25kmh / INT: 20mph BATTERY – PowerTube 625Wh DISPLAY – Bosch Purion CHARGER – 4A Charger
Rear Deraileur
Shimano XT / 12 Speed
Shifter(s)
Shimano SL-M6100
Crankset
FSA CK-745 165mm / 34T
Cassette
Shimano CS-M6100 / 10-51 T
Brakes
Shimano BR-MT520 4 Piston
Handlebar
Syncros Hixon 2.0 Rise / Alloy 6061D.B. 20mm rise / 8° / 800mm, Syncros Pro lock-on grips
Stem
Syncros XM1.5 / Alloy 6061, integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8″
Seatpost
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 125mm / M size 150mm / L & XL size 170mm
Saddle
Syncros Tofino 2.0 Regular, CRMO rails
Headset
Acros Blocklock / Tapered 1.5″-1 1/8″, OD 52/62mm / ID 44/56mm
Hub Front
Shimano HB-MT410-B CL / 15x110mm
Hub Rear
Shimano FH-MT410-B CL / Boost 12x148mm
Rims
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
Tires
FRONT TIRE – Maxxis Assegai 29×2.6″, 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra REAR TIRE – Maxxis Dissector 29×2.6″, 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra
Weight (Approx lbs)
54.67
